CXFR-** VGA/HD/USB/Audio/RS232 over optical fibre receiver
The C.A. Designs IP Workstation Receiver CXFR-** is part of a line interface for the transport of most of the commonly used signals from a PC, throughout buildings wired with optical fibre, to remote user locations. The CXFR-** receiver is designed to work with our CXFT-** transmitters.
The CXFR-** video outputs match most of the commonly available monitors. Mouse, keyboard and audio can also be extended using the CXFR-**. This allows devices such as printers, USB memory and webcams to be remotely located.
Models available:
| Product Code | Video Type | Max Distance | Cable type |
|---|---|---|---|
| CXFR-V1 | VGA only | 100m | Cat5 |
| CXFR-V2 | VGA only | 500m | Multimode fibre |
| CXFR-H1 | HD only | 100m | Cat5 |
| CXFR-H2 | HD only | 500m | Multimode fibre |
For applications requiring further than 500m, we can offer a single-mode fibre version, please contact us for details.
All models provide excellent picture quality with resolutions up to WUXGA (1920 x 1200).
Available connections:
- VGA out - Standard 15 way HDD female
- HD out - Standard HD female
- RS232 - 9 way D male
- Audio - Mic in, and audio out mini jack sockets
- USB - 4 x type 'A' connectors
Power is provided from an external +5V regulated power supply (included).
Click Here for datasheet.
